BV004010 Side Bend, Horizontal Bend, Side Emitting LED Neon Light, UL, TUV CE, CB Certficates
BV004010 side emitting, horizontal bend, side bending LED neon light
BLUEVISION LED neon light features:
Dual-color silicone extrusion(IP67)/tube(IP65) +flexible FPC+highlight LED;
High light transmittance;
Anti-UV;
Flxible;
Mild and even light output;
Cuttable and bendable;
Hollow inside, protect LEDs well;
IP65, Warranty 5-year, >50000 hours (L70B10) (Not suitable for immersion in water)
IP67, Warranty 5-year, >50000 hours (L70B10) (Not suitable for long-term immersion in water deeper than 0.5m);
Helps to set up an energy saving, flexible and multifunctional lighting effect, the products with the features of good heat radiation, anti-yellowing, strong weather resistance and easy installation.
Parameter:
LED Neon Light transmittance: 19%
Input voltage: 24VDC
Beam angle: 113°
Anti-UV grade: UVA-340
Material: LED strip light+silicone
Weight/meter: 138g
IP grade: IP67/IP65
Operating temperature: -20℃～+45℃
Storage temperature: 0℃～+60℃
Parameter:
| Item NO. | BV004010 Tricolor-color silicone extrusion |
| Size | 5020mm (197.64”) x 4mm(0.16”) x 10mm(0.39”) |
| Power | 7.2W/m |
| Voltage | DC24V |
| Light transmittance | 19% |
Minimum cutting | 50MM |
| CCT LED origin | 2700K I 3300K I 4300K I 6000K |
| CCT after silicone extrusion | 2500K~2700K I 2900K~3100K I 3700K~4200K I 5050K~5650K |
| Lumen/meter | 152 LM/M I 159 LM/M I 175 LM/M I 165 LM/M |
| Strip options | S2835L140V24-6 |
| Anti-uv grade | UVA-340 |
| CRI (Ra>) | 90 + |
| IP Rating | IP 67 |
| Beam Angle | 115° |
| Weight/meter | 138g |
| Material | Silicone |
| Warranty | Warranty 5-year, >50000 hours (L70B10) (Not suitable for long-term immersion in water deeper than 0.5m) |
| Operating temperature | -20℃ ~ +45℃ |
| Storage temperature | 0℃ ~ +60℃ |
| Item NO. | BV004010 Dual-color silicone tube |
| Size | 5020mm (197.64”) x 4.3mm(0.17”) x 10.3mm(0.40”) |
| Power | 7.2W/m |
| Voltage | DC24V |
| Light transmittance | 20% |
Minimum cutting | 50MM |
| CCT LED origin | 2700K I 3300K I 4300K I 6000K |
| CCT after silicone extrusion | 2500K~2700K I 2900K~3100K I 3700K~4200K I 5050K~5650K |
| Lumen/meter | 158 LM/M I 165 LM/M I 181 LM/M I 171 LM/M |
| Strip options | S2835L140V24-6 |
| Anti-uv grade | UVA-340 |
| CRI (Ra>) | 90 + |
| IP Rating | IP 65 |
| Beam Angle | 115° |
| Weight/meter | 138g |
| Material | Silicone |
| Warranty | Warranty 5-year, >50000 hours (L70B10) (Not suitable for immersion in water) |
| Operating temperature | -20℃ ~ +45℃ |
| Storage temperature | 0℃ ~ +60℃ |
