Dual-color 30° IP67 125mm/7LEDs LED Wall Washer Light, LED Grazer Light BVW012008

share
WeChat
Sina Weibo
QQ
QQ space
Douban
Baidu Post Bar
copy Link
Facebook
X
LinkedIn
Model BVW012008
Detailed item code S2835D56V24WW27K+W65K9IP67-10-A30
FPC width 10mm
Cutting unit 125mm
Power 19.2w/meter
Operating temperature -20℃～+45℃
Storage temperature 0℃～+60℃
Environment humidity 40～70% RH
Standard length 5 meters per roll
Application Indoor/Outdoor
Protection grade IP67
Detail

Parameter:



Item NO.     BVW012008
Size     5020mm×12mm×8mm
Power     19.2W/m (5.85W/ft)
FPC
     S2835D56V24WW27K+W65K9IP67-12-A30
Voltage     DC24V
PCB Width     10mm
LED/m     56pcs/m
CCT     2700K~6500K adjustable
Lumen/meter     2700K 880lm/m         6500K 1033lm/m           2700K+6500K 1880lm/m
CRI (Ra>)     90 +
Cut length     125mm/unit
Beam Angle     30°
IP Rating     IP67
Warranty     Warranty 3-year, >30000 hours (L70B10)
Operating temperature     -20℃ ~ +45℃
Storage temperature     0℃ ~ +60℃





‍
