Dual-color 30°/25×45° IP67 125mm/3LEDs LED Wall Washer Light, LED Grazer Light BVW020010

share
WeChat
Sina Weibo
QQ
QQ space
Douban
Baidu Post Bar
copy Link
Facebook
X
LinkedIn
Model BVW020010
Detailed item code S2835D48V24WW27K+W65K9IP67-15-AXX
FPC width 15mm
Cutting unit 125mm
Power 24w/meter
Operating temperature -20℃～+45℃
Storage temperature 0℃～+60℃
Environment humidity 40～70% RH
Standard length 5 meters per roll
Application Indoor/Outdoor
Protection grade IP67
Detail

Parameter:



Item NO.     BVW020010
Size     5020mm×19.5mm×10mm
Power     24W/m (7.32W/ft)
FPC
     S2835D48V24WW27K+W65K9IP67-15
Voltage     DC24V
PCB Width     15mm
LED/m     48pcs/m
CCT     2700K~6500K adjustable
Lumen/meter     2700K 1366lm/m         6500K 905lm/m           2700K+6500K 2258lm/m
CRI (Ra>)     90 +
Cut length     125mm/unit
Beam Angle     30°
IP Rating     IP67
Warranty     Warranty 5-year, >50000 hours (L70B10) for indoor usage，Warranty 3-year, >30000 hours (L70B10) for outdoor usage
Operating temperature     -20℃ ~ +45℃
Storage temperature     0℃ ~ +60℃


‍
