BVD25C 255° curved neon light Endless connection without dark zone, UL, TUV CE, CB certficates
share
Detail
| Item NO. | BVD25C |
| Size | 5005mm (197.05”) x Φ25mm(0.98’’) |
| Power | 14.4W/m (4.4W/FT) |
| Voltage | DC24V |
| Light transmittance | 83% |
Bending radius | R≥200mm |
| CCT LED origin | 2700K I 3000K I 4000K I 6000K |
| CCT after silicone extrusion | 2600K~2800K I 2900K~3100K I 3800K~4200K I 5600K~6200K |
| Lumen/meter | 1152 LM/M I 1184 LM/M I 1340 LM/M I 1257 LM/M |
| Strip options | S2835L140V24-8 |
| Anti-uv grade | UVA-340 |
| CRI (Ra>) | 90 + |
| IP Rating | IP 20 |
| Beam Angle | 255° |
Minimum cutting | 50mm |
| Material | Silicone + aluminum |
| Warranty | Warranty 5-year, >50000 hours (L70B10) |
| Operating temperature | -20℃ ~ +45℃ |
| Storage temperature | 0℃ ~ +60℃ |
| Item NO. | BVD25C（Dual-colour） |
| Size | 5005mm (197.05”) x Φ25mm(0.98’’) |
| Power | 14.4W/m (7.2*2W/m) |
| Voltage | DC24V |
| Light transmittance | 83% |
Bending radius | R≥200mm |
| CCT LED origin | 2700K I 4300K I 6000K |
| CCT after silicone extrusion | 2500K~2700K I 4000K~4400K I 5550K~6150K |
| Lumen/meter | 598 LM/M I 1274 LM/M I 675 LM/M |
| Strip options | S2835D140V24-8(2-in-1) |
| Anti-uv grade | UVA-340 |
| CRI (Ra>) | 90 + |
| IP Rating | IP 20 |
| Beam Angle | 255° |
Minimum cutting | 50mm |
| Material | Silicone + aluminum |
| Warranty | Warranty 5-year, >50000 hours (L70B10) |
| Operating temperature | -20℃ ~ +45℃ |
| Storage temperature | 0℃ ~ +60℃ |
| Item NO. | BVD25C（“ S ” Shape） |
| Size | 15015mm (591.14”) x Φ25mm(0.98’’) |
| Power | 14.4W/m (4.4W/m) |
| Voltage | DC24V |
| Light transmittance | 83% |
Bending radius | R≥200mm |
| CCT LED origin | 2700K I 3000K I 4000K I 6000K |
| CCT after silicone extrusion | 2600K~2800K I 2900K~3100K I 3800K~4200K I 5600K~6200K |
| Lumen/meter | 1152 LM/M I 1184 LM/M I 1340 LM/M I 1257 LM/M |
| Strip options | S2835L140V24-12-S |
| Anti-uv grade | UVA-340 |
| CRI (Ra>) | 90 + |
| IP Rating | IP 20 |
| Beam Angle | 255° |
Minimum cutting | 50mm |
| Material | Silicone + aluminum |
| Warranty | Warranty 5-year, >50000 hours (L70B10) |
| Operating temperature | -20℃ ~ +45℃ |
| Storage temperature | 0℃ ~ +60℃ |
| Item NO. | BVD25C（DC48V） |
| Size | 25020mm (985.04”) x Φ25mm(0.98’’) |
| Power | 9.6W/m (2.93W/FT) |
| Voltage | DC48V |
| Light transmittance | 83% |
Bending radius | R≥200mm |
| CCT LED origin | 2700K I 3000K I 4000K I 6000K |
| CCT after silicone extrusion | 2600K~2800K I 2900K~3100K I 3800K~4200K I 5600K~6200K |
| Lumen/meter | 805 LM/M I 826 LM/M I 933 LM/M I 868 LM/M |
| Strip options | S2835L140V48-8 |
| Anti-uv grade | UVA-340 |
| CRI (Ra>) | 90 + |
| IP Rating | IP 20 |
| Beam Angle | 255° |
Minimum cutting | 100mm |
| Material | Silicone + aluminum |
| Warranty | Warranty 5-year, >50000 hours (L70B10) |
| Operating temperature | -20℃ ~ +45℃ |
| Storage temperature | 0℃ ~ +60℃ |
