S2835L60V12 China LED strip light
Product name: China LED strip light / LED ribbon light / LED tape light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L60V12
LED type: SMD2835
LED quantity per meter: 60 LEDs
Input voltage: 12VDC
Power: 7.2W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 730~850lm/meter (222~259lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L60V12XXXIP20-8 LED strip specification sheet.pdf
2.2MB
S2835L60V12-S S shape China LED ribbon light
Product name: China LED strip light / LED ribbon light / LED tape light
Item code: S2835L60V12-S
LED type: SMD2835
LED quantity per meter: 60 LEDs
Input voltage: 12VDC
Power: 7.2W/meter
FPC width: 6mm (0.24 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 730~850lm/meter (222~259lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L60V12XXXIP20-6-S LED strip specification sheet.pdf
2MB
S2835L60V24 China LED tape light
Product name: China LED strip light / LED ribbon light / LED tape light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L60V24
LED type: SMD2835
LED quantity per meter: 60 LEDs
Input voltage: 24VDC
Power: 7.2W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 730~850lm/meter (222~259lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L60V24XXXIP20-8 LED strip specification sheet.pdf
2.2MB
S2835L60C24 Constant current China LED strip light
Product name: Constant current LED strip light / LED ribbon light / LED tape light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L60C24
LED type: SMD2835
LED quantity per meter: 60 LEDs
Input voltage: 24VDC
Power: 7.2W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20, IP55, IP66, IP678
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 730~850lm/meter (222~259lm/ft)
Standard length: 20 meters (65.6ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L60C24XXXIP20-10 LED strip specification sheet.pdf
2.2MB
S2835D60V24 CCT tunable China LED ribbon light
Product name: CCT tunable LED strip light / LED ribbon light / LED tape light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835D60V24
LED type: SMD2835
LED quantity per meter: 60 LEDs
Input voltage: 24VDC
Power: 8.6W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 166.7mm (0.55ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K~6000K CCT tunable
CRI: 80+/90+
Brightness: 0~800lm/meter (0~244lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835D60V24XXXIP20-10 LED strip specification sheet.pdf
2.1MB
S2835L80V24 ultra high light efficacy led strip light
Product name: Ultra high light efficacy LED strip light / LED tape light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L80V24
LED type: SMD2835
LED quantity per meter: 80 LEDs
Input voltage: 24VDC
Power: 7.2W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 970~1100lm/meter (295~335lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L80V24XXXIP20-8 LED strip specification sheet.pdf
2.2MB
S2835L98V24 China LED ribbon light
Product name: China LED strip light / LED ribbon light / LED tape light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L98V24
LED type: SMD2835
LED quantity per meter: 98 LEDs
Input voltage: 24VDC
Power: 10W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 71.4mm (0.234ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1150~1400lm/meter (350~427lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L98V24XXXIP20-8 LED strip specification sheet.pdf
2.1MB
S2835L120V12 China LED tape light
Product name: China LED strip light / LED ribbon light / LED tape light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L120V12
LED type: SMD2835
LED quantity per meter: 120 LEDs
Input voltage: 12VDC
Power: 14.4W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 25mm (0.082ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1450~1670lm/meter (442~509lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L120V12XXXIP20-8 LED strip specification sheet.pdf
2.2MB
S2835L120V24 LED strip light
Product name: China LED tape light / LED ribbon light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L120V24
LED type: SMD2835
LED quantity per meter: 120 LEDs
Input voltage: 24VDC
Power: 14.4W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1450~1670lm/meter (442~509lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L120V24XXXIP20-8 LED strip specification sheet.pdf
2.1MB
S2835L120V24-T T shape led strip light
Product name: China LED tape light / LED ribbon light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L120V24-T
LED type: SMD2835
LED quantity per meter: 120 LEDs
Input voltage: 24VDC
Power: 14.4W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1450~1670lm/meter (442~509lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L120V24XXXIP20-10-T LED strip specification sheet.pdf
2MB
S2835L120C24 Constant current LED strip light
Product name: China LED tape light / LED ribbon light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L120C24
LED type: SMD2835
LED quantity per meter: 120 LEDs
Input voltage: 24VDC
Power: 14.4W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1450~1700lm/meter (442~518lm/ft)
Standard length: 10 meters (32.8ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L120C24XXXIP20-10 LED strip specification sheet.pdf
2.2MB
S2835D120V24 CCT tunable led strip light
Product name: CCT tunable LED tape light / LED ribbon light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835D120V24
LED type: SMD2835
LED quantity per meter: 120 LEDs
Input voltage: 24VDC
Power: 14.4W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 0~1550lm/meter (0~472lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835D120V24XXXIP20-10 LED strip specification sheet.pdf
2.1MB
S2835L140V24 led strip light
Product name: China LED tape light / LED ribbon light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L140V24
LED type: SMD2835
LED quantity per meter: 140 LEDs
Input voltage: 24VDC
Power: 14.4W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1700~1950lm/meter (518~594lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L140V24XXXIP20-10 LED strip specification sheet.pdf
2.0MB
S2835L140V24 Chinese led strip light
Product name: China LED tape light / LED ribbon light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L140V24
LED type: SMD2835
LED quantity per meter: 140 LEDs
Input voltage: 24VDC
Power: 15W/meter
FPC width: 12mm (0.47 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1740~2020lm/meter (530~616lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L140V24XXXIP20-12 LED strip specification sheet.pdf
1.9MB
S2835L160V24 ultra high light efficacy led strip light
Product name: Ultra high light efficacy LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L160V24
LED type: SMD2835
LED quantity per meter: 160 LEDs
Input voltage: 24VDC
Power: 14.4W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1950~2230lm/meter (594~680lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L160V24XXXIP20-10 LED strip specification sheet.pdf
2.0MB
S2835L168V24 Chinese LED tape light
Product name: China LED tape light / LED ribbon light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L168V24
LED type: SMD2835
LED quantity per meter: 168 LEDs
Input voltage: 24VDC
Power: 17.3W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 41.7mm (0.137ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 2050~2340lm/meter (625~713lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L168V24XXXIP20-10 LED strip specification sheet.pdf
2MB
S2835L196V24 Chinese LED strip light
Product name: China LED tape light / LED ribbon light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L196V24
LED type: SMD2835
LED quantity per meter: 196 LEDs
Input voltage: 24VDC
Power: 20.2W/meter
FPC width: 15mm (0.59 in)
Cutting unit: 71.4mm (0.234ft)
Optional IP grade: IP20, IP65, IP66, IP67
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 2350~2750lm/meter (716~838lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L196V24XXXIP20-15 LED strip specification sheet.pdf
2MB
S2835L224V24 ultra high light efficacy led strip light
Product name: Ultra high light efficacy LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L224V24
LED type: SMD2835
LED quantity per meter: 224 LEDs
Input voltage: 24VDC
Power: 20.2W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 35.7mm (0.117ft)
Optional IP grade: IP20, IP55, IP65, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 2740~3120lm/meter (835~951lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L224V24XXXIP20-10 LED strip specification sheet.pdf
2MB
S2835L252V24 chinese led strip light
Product name: China LED tape light / LED ribbon light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L252V24
LED type: SMD2835
LED quantity per meter: 252 LEDs
Input voltage: 24VDC
Power: 25.9W/meter
FPC width: 19mm (0.75 in)
Cutting unit: 83.3mm (0.273ft)
Optional IP grade: IP20, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 3080~3510lm/meter (939~1070lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L252V24XXXIP20-19 LED strip specification sheet.pdf
2MB
S2835L280V24 china led strip light
Product name: China LED ribbon light / LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L280V24
LED type: SMD2835
LED quantity per meter: 280 LEDs
Input voltage: 24VDC
Power: 25W/meter
FPC width: 24mm (0.94 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 2880~3330lm/meter (878~1015lm/ft)
Standard length: 2.5 meters (8.2ft) or 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L280V24XXXIP20-24 LED strip specification sheet.pdf
2.1MB
S2835L280V24 chinese led strip light
Product name: China LED ribbon light / LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L280V24
LED type: SMD2835
LED quantity per meter: 280 LEDs
Input voltage: 24VDC
Power: 30W/meter
FPC width: 30mm (1.18 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 3485~4035lm/meter (1061~1230lm/ft)
Standard length: 2.5 meters (8.2ft) or 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L280V24XXXIP20-30 LED strip specification sheet.pdf
2.0MB
S2835L280V24 china led tape light
Product name: China LED ribbon light / LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L280V24
LED type: SMD2835
LED quantity per meter: 280 LEDs
Input voltage: 24VDC
Power: 28.8W/meter
FPC width: 36mm (1.42 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 3420~3895lm/meter (1042~1187lm/ft)
Standard length: 2.5 meters (8.2ft) or 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L280V24XXXIP20-36 LED strip specification sheet.pdf
2.1MB
S2835L350V24 led ribbon light
Product name: China LED ribbon light / LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L350V24
LED type: SMD2835
LED quantity per meter: 350 LEDs
Input voltage: 24VDC
Power: 36W/meter
FPC width: 58mm (2.28 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 4280~4870lm/meter (1305~1484lm/ft)
Standard length: 2.5 meters (8.2ft) or 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L350V24XXXIP20-58 LED strip specification sheet.pdf
2.2MB
S2835L420V24 chinese led tape light
Product name: China LED ribbon light / LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2835L420V24
LED type: SMD2835
LED quantity per meter: 420 LEDs
Input voltage: 24VDC
Power: 40W/meter
FPC width: 40mm (1.57 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 4610~5315lm/meter (1406~1620lm/ft)
Standard length: 2.5 meters (8.2ft) or 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2835L420V24XXXIP20-40 LED strip specification sheet.pdf
2.2MB
S2216L120V24 led strip light
Product name: China LED ribbon light / LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2216L120V24
LED type: SMD2216
LED quantity per meter: 120 LEDs
Input voltage: 24VDC
Power: 9.6W/meter
FPC width: 4mm (0.16 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 90+
Brightness: 650~750lm/meter (198~229lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2216L120V24XXXIP20-4 LED strip specification sheet.pdf
2.9MB
S2216L120V24 led strip light
Product name: China LED ribbon light / LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2216L120V24
LED type: SMD2216
LED quantity per meter: 120 LEDs
Input voltage: 24VDC
Power: 9.6W/meter
FPC width: 5mm (0.2 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 90+
Brightness: 650~750lm/meter (198~229lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2216L120V24XXXIP20-5 LED strip specification sheet.pdf
1.9MB
S2216L120V24 led strip light
Product name: China LED ribbon light / LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2216L120V24
LED type: SMD2216
LED quantity per meter: 120 LEDs
Input voltage: 24VDC
Power: 9.6W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 90+
Brightness: 650~750lm/meter (198~229lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2216L120V24XXXIP20-8 LED strip specification sheet.pdf
2.2MB
S2216L180V24 china led strip light
Product name: China LED ribbon light / LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2216L180V24
LED type: SMD2216
LED quantity per meter: 180 LEDs
Input voltage: 24VDC
Power: 14.4W/meter
FPC width: 5mm (0.2 in)
Cutting unit: 33.3mm (0.109ft)
Optional IP grade: IP20, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 90+
Brightness: 998~1140lm/meter (304~348lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2216L180V24XXXIP20-5 LED strip specification sheet.pdf
2.9MB
S2216L240V24 china led strip light
Product name: China LED ribbon light / LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2216L240V24
LED type: SMD2216
LED quantity per meter: 240 LEDs
Input voltage: 24VDC
Power: 19.2W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 25mm (0.082ft)
Optional IP grade: IP20, IP55, IP65, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 90+
Brightness: 1300~1550lm/meter (396~472lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2216L240V24XXXIP20-10 LED strip specification sheet.pdf
2.0MB
S2216L300V24 china led strip light
Product name: China LED ribbon light / LED tape light / LED strip light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2216L300V24
LED type: SMD2216
LED quantity per meter: 300 LEDs
Input voltage: 24VDC
Power: 12W/meter
FPC width: 6mm (0.24 in)
Cutting unit: 20mm (0.065ft)
Optional IP grade: IP20, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 90+
Brightness: 865~988lm/meter (264~301lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2216L300V24XXXIP20-6 LED strip specification sheet.pdf
3MB
S2216L300V24 china led strip light
Product name: China LED strip light / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2216L300V24
LED type: SMD2216
LED quantity per meter: 300 LEDs
Input voltage: 24VDC
Power: 12W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 20mm (0.065ft)
Optional IP grade: IP20, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 90+
Brightness: 865~988lm/meter (264~301lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2216L300V24XXXIP20-8 LED strip specification sheet.pdf
4.7MB
S2216L320V24 china led strip light
Product name: China LED strip light / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S2216L320V24
LED type: SMD2216
LED quantity per meter: 320 LEDs
Input voltage: 24VDC
Power: 19.2W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 25mm (0.082ft)
Optional IP grade: IP20, IP55, IP65, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 90+
Brightness: 1750~2050lm/meter (533~625lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S2216L320V24XXXIP20-10 LED strip specification sheet.pdf
2.0MB
S5050L30V12 china led tape light
Product name: China LED strip light / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S5050L30V12
LED type: SMD5050
LED quantity per meter: 30 LEDs
Input voltage: 12VDC
Power: 7.2W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 650~750lm/meter (198~229lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S5050L30V12XXXIP20-10 LED strip specification sheet.pdf
2.2MB
S5050L30V24 chinese led tape light
Product name: China LED strip light / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S5050L30V24
LED type: SMD5050
LED quantity per meter: 30 LEDs
Input voltage: 24VDC
Power: 8.6W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 166.7mm (0.55ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 650~750lm/meter (198~229lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S5050L30V24XXXIP20-10 LED strip specification sheet.pdf
2.2MB
S5050L60V12 china led tape light
Product name: China LED strip light / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S5050L60V12
LED type: SMD5050
LED quantity per meter: 60 LEDs
Input voltage: 12VDC
Power: 14.4W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1300~1500lm/meter (396~457lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S5050L60V12XXXIP20-10 LED strip specification sheet.pdf
2.2MB
S5050L60V24 led tape light
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S5050L60V24
LED type: SMD5050
LED quantity per meter: 60 LEDs
Input voltage: 24VDC
Power: 14.4W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1300~1500lm/meter (396~457lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S5050L60V24XXXIP20-10 LED strip specification sheet.pdf
2.2MB
S5050L72V12 led tape light
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S5050L72V12
LED type: SMD5050
LED quantity per meter: 72 LEDs
Input voltage: 12VDC
Power: 17.3W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 13.9mm (0.046ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1600~1800lm/meter (488~549lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S5050L72V12XXXIP20-10 LED strip specification sheet.pdf
2.2MB
S5050M30V12RGB led tape light
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S5050M30V12RGB
LED type: SMD5050RGB
LED quantity per meter: 30 LEDs
Input voltage: 12VDC
Power: 7.2W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard color: RGB
Brightness: RGB 260lm/m (79lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S5050M30V12RGB0IP20-10 LED strip specification sheet.pdf
2.0MB
S5050M30V12RGBW china led tape light
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S5050M30V12RGBW
LED type: SMD5050RGBW
LED quantity per meter: 30 LEDs
Input voltage: 12VDC
Power: 9.6W/meter
FPC width: 12mm (0.47 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard color: RGB+WW2700K, WW3000K, NW4000K, W6000K
Brightness: 180~195lm/m (55~59lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S5050M30V12RGBW8IP20-12 LED strip specification sheet.pdf
1.8MB
S5050M60V12RGB china led tape light
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S5050M60V12RGB
LED type: SMD5050RGB
LED quantity per meter: 60 LEDs
Input voltage: 12VDC
Power: 14.4W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard color: RGB
Brightness: RGB 520lm/m (158lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S5050M60V12RGB0IP20-10 LED strip specification sheet.pdf
2.0MB
S5050M60V24RGB china led tape light
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S5050M60V24RGB
LED type: SMD5050RGB
LED quantity per meter: 60 LEDs
Input voltage: 24VDC
Power: 14.4W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard color: RGB
Brightness: RGB 520lm/m (158lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S5050M60V24RGB0IP20-10 LED strip specification sheet.pdf
2.0MB
S5050M60V24RGBW china led tape light
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S5050M60V24RGBW
LED type: SMD5050RGBW
LED quantity per meter: 30 LEDs
Input voltage: 24VDC
Power: 19.2W/meter
FPC width: 12mm (0.47 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard color: RGB+WW2700K, WW3000K, NW4000K, W6000K
Brightness: 360~390lm/m (110~119lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S5050M60V24RGBW8IP20-12 LED strip specification sheet.pdf
1.9MB
S5050M72V24RGB chinese led tape light
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S5050M72V24RGB
LED type: SMD5050RGB
LED quantity per meter: 72 LEDs
Input voltage: 24VDC
Power: 17.2W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 83.3mm (0.27ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard color: RGB
Brightness: RGB 620lm/m (189lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S5050M72V24RGB0IP20-10 LED strip specification sheet.pdf
2.0MB
S3528L60V12 china led tape light
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S3528L60V12
LED type: SMD3528
LED quantity per meter: 60 LEDs
Input voltage: 12VDC
Power: 4.8W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 390~450lm/meter (118~137lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S3528L60V12XXXIP20-8 LED strip specification sheet.pdf
2.2MB
S3528L60V24 China LED strip lights
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S3528L60V24
LED type: SMD3528
LED quantity per meter: 60 LEDs
Input voltage: 24VDC
Power: 4.8W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 100mm (0.328ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 390~450lm/meter (118~137lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S3528L60V24XXXIP20-8 LED strip specification sheet.pdf
2.1MB
S3528L120V12 China LED strip lights
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S3528L120V12
LED type: SMD3528
LED quantity per meter: 120 LEDs
Input voltage: 12VDC
Power: 9.6W/meter
FPC width: 5mm (0.2 in)
Cutting unit: 25mm (0.082ft)
Optional IP grade: IP20, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 790~880lm/meter (241~268lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S3528L120V12XXXIP20-5 LED strip specification sheet.pdf
2.0MB
S3528L120V12 LED strip light
Product name: China LED strip lights / LED tape light / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S3528L120V12
LED type: SMD3528
LED quantity per meter: 120 LEDs
Input voltage: 12VDC
Power: 9.6W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 25mm (0.082ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 790~880lm/meter (241~268lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S3528L120V12XXXIP20-8 LED strip specification sheet.pdf
2.2MB
S3528L120V24 LED strip light
Product name: China LED tape light / LED strip lights / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S3528L120V24
LED type: SMD3528
LED quantity per meter: 120 LEDs
Input voltage: 24VDC
Power: 9.6W/meter
FPC width: 8mm (0.31 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP55, IP65, IP66, IP67, IP68
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 790~880lm/meter (241~268lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S3528L120V24XXXIP20-8 LED strip specification sheet.pdf
2.1MB
S3528L240V24 LED strip light
Product name: China LED tape light / LED strip lights / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S3528L240V24
LED type: SMD3528
LED quantity per meter: 240 LEDs
Input voltage: 24VDC
Power: 19.2W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 25mm (0.082ft)
Optional IP grade: IP20, IP55, IP65, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1590~1760lm/meter (485~537lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S3528L240V24XXXIP20-10 LED strip specification sheet.pdf
2MB
S3528L240V24-H high light efficacy led strip light
Product name: High light efficacy LED tape light / LED strip lights
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S3528L240V24-H
LED type: SMD3528
LED quantity per meter: 240 LEDs
Input voltage: 24VDC
Power: 14.4W/meter
FPC width: 10mm (0.39 in)
Cutting unit: 33mm (0.108ft)
Optional IP grade: IP20, IP55, IP65, IP66
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1590~1760lm/meter (485~537lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S3528L240V24XXXIP20-10-H LED strip specification sheet.pdf
2.0MB
S3528L240V24 led strip light
Product name: China LED tape light / LED strip lights / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S3528L240V24
LED type: SMD3528
LED quantity per meter: 240 LEDs
Input voltage: 24VDC
Power: 19.2W/meter
FPC width: 15mm (0.59 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP65, IP66, IP67
Beam angle:120°
Standard CCT: 2700K/3000K/4000K/6000K (2300K/3500K/5000K)
CRI: 80+/90+
Brightness: 1590~1760lm/meter (485~537lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S3528L240V24XXXIP20-15 LED strip specification sheet.pdf
2.0MB
S3528D240V24 CCT tunable led strip light
Product name: CCT tunable LED tape light / LED strip lights / LED ribbon light
Certificate: UL (control number: E487469), CE and CB (TUV Rheinland)
Item code: S3528D240V24
LED type: SMD3528
LED quantity per meter: 240 LEDs
Input voltage: 24VDC
Power: 0~19.2W/meter
FPC width: 15mm (0.59 in)
Cutting unit: 50mm (0.164ft)
Optional IP grade: IP20, IP65, IP66, IP67
Beam angle:120°
Standard CCT: 2700K~6000K CCT tunable
CRI: 80+/90+
Brightness: 0~1600lm/meter (0~488lm/ft)
Standard length: 5 meters (16.4ft) per roll
Working time≥50000H
Application: commercial, airport, shopping mall, home etc.
Warranty: non-waterproof, 5 years; waterproof, 3 years

S3528D240V24XXXIP20-15 LED strip specification sheet.pdf
2MB
